DENSO

DENSO SALES CALIFORNIA, INC.

3900 Via Oro Avenue, Long Beach, CA 90810

BULLETIN NO: MB06-0001

MODEL: CM12

DATE: 08-14-06

PAGES: 1 of 3

MOVINCOOL SERVICE INFORMATION

TITLE: CM12 Thermostat Compatibility and Installation

UNIT AFFECTED: CM12

CONDITION: Unit is not compatible with 24V AC thermostat

CORRECTION: Use only thermostat that is compatible with Millivolt- System

Note: Do not connect thermostat to AC power source.

Preparation for Thermostat Connection

1. Use with a single stage wall thermostat (Millivolt-System).

2. Set the wall thermostat to cooling system mode, since most wall thermostats

are designed for both heating and cooling.

3. Prepare the wire harness for connection from the unit to the thermostat.

The recommended wire size is: 16-26 AWG.

Wire type: Thermostat cable/ solid wire.

4. Identify the thermostat connectors labeled G, G1, Y, and RC.

G (Fan on/off), G1 (Fan speed HI/LO), Y (cooling on/off), and RC

(Cooling Transfer-Common).

Wall Thermostat Connector

Name

CM12 WIRES

Function

Label Name

Color

Brown

Common

Red

Cool On/Off

Orange

Fan On/Off

Yellow

Fan Hi/Low

5. Install the wall thermostat to the proper location inside the room where it can be conven-

iently accessed. Do not install the wall thermostat where unusual heating

condition may occur (i.e. hot stove, hot pipe, fireplace, direct sunlight, etc.)

6. Most thermostats provide these basic functions:

Fan Mode: On / Auto (Select the desire fan mode)

System: Cool / Heater (Select cool only)

If you have any questions concerning the above information, please call the Technical Support Hotline at (800) 264-9573

3900 Via Oro Avenue, Long Beach, CA 90810

1 2 3

DENSO SALES CALIFORNIA, INC 1

Resumo do Conteúdo

Página 1 - DENSO SALES CALIFORNIA, INC

DENSODENSO SALES CALIFORNIA, INC.3900 Via Oro Avenue, Long Beach, CA 90810 BULLETIN NO: MB06-0001MODEL: CM

Página 2

DIAGRAM FOR THERMOSTAT CONNECTION RCYGG1 ThermostatCM12 UnitConnect only if thermostat has Fan Hi-Lo speed control (Millivolt Syst

Página 3

CM12 CAN BE USED WITH STANDARD MILLIVOLT THERMOSTATSCompatibility of the Following Wall Thermostats is Confirmed:HONEYWELL RTH 110BHUNTER 40035A–350
